ONKA 6mm2 spring terminal strip terminal strip DIN rail 2-wire gray, 1020034
- Regular price
- 6,12 zł
- Regular price
-
- Sale price
- 6,12 zł
- Unit price
- per
Couldn't load pickup availability
Notified by email when this product becomes available
- Description
- Payment methods
- Warranty
Spring terminal block busbar connector / 2-wire DIN rail clamp, recessed contact, gray, ONKA, made in Turkey
Compact ONKA busbar connectors provide great possibilities for connecting any wires of different cross-sections. The transparent housing makes it easy to check the correct arrangement of the wires. Original ONKA quick connectors offer installation convenience and 100% connection reliability.
Technical parameters
Cross-section of connected single wire up to: 6mm2
Color: gray
Insulating material of main housing: polyamide (PA6.6)
Contact/bridge material: stainless steel/copper
Connection position: top / top
Cable strip length: 12mm
Type of electrical connection: spring clamp / recessed contact
Rated voltage: 750V
Rated current: 41A
Operating temperature range from: -40°C
Operating temperature range to: 140°C
Mounting method: DIN 35 mm mounting rail
Standard: EN-60947-7-1
